Exploring AI to the deep end – Facebook Reels

Today was exploring more of AI tools and many more.

Using chat-gpt generated a prompt for leonardo ai to create a subtle scenery.

Using GIMP on Ubuntu the scene was upscaled and cropped to 810:1440 ie 9:16 resolution. Used AI Music to generate a 30 second lo-fi bgm.mp3. using a PHP script generated 840 lines in format fname brightness contrast with values in a gradual change. This information was used in a loop for invoking imagemagic convert and create 840 frames. finally ffmpeg -i “%04d.jpg” -i bgm.mp3 -r 30 dusk.mp4. since frame rate is 30 and frames are 840, the video is of length 28 seconds and can be shared on facebook as a reel. That was my target.

Prompt in Chat GPT:

Suggest a detailed prompt for leonardo ai to generate a scenic view of country side just before sunset and the sun is behind the viewer.

The response, trimmed to the relevant portion which was further given to Leonardo AI:

A breathtaking countryside landscape bathed in the warm glow of the golden hour, just before sunset. The sun is behind the viewer, casting long, soft shadows over rolling green hills. A winding dirt road leads through fields of wildflowers in shades of lavender, yellow, and white, gently swaying in the breeze. A rustic wooden fence lines the path, guiding the eye toward a quaint farmhouse with a red roof and smoke curling from its chimney. Lush trees with golden-hued leaves dot the horizon, their branches swaying gently. A calm river reflects the soft, pastel hues of the evening sky—lavender, peach, and rose gold—while birds soar gracefully in the distance. The scene exudes warmth, tranquility, and a sense of peaceful solitude.

This was of dimension 1472×832 though I had set 16:9 resolution in the Leonardo image generator app.

Since I am on XUbuntu here I used GIMP to first upscale. As height required was 1440 the width proportionally came to 2548 once the scaling was done, chose canvas size from the image menu. setting width to 810 and position to center, since I needed 9:16 for Facebook reel.

Now for progressive frame generation a short script was written. For which the max thresholds were identified using GIMP. Colors -> Brightness & Contrast then in the slider, manually tweaking until the image was fully black. tried to fix these values to easy to calculate. And arrived at Brightness -120 and Contrast + 60. With a frame rate of 30 per second, a 28 second video will need 840 frames. So applying that brightness is 0 to -120 in 840 frames which evaluates to reduce by 1 in every 7 frames, whereas contrast is 0 to 60 and that evaluates to increase of 1 in every 14 frames. This was implemented using php scripting.

<?php

/*
brightness    0 => -120  7:1
Contrast      0 => 60   14:1

frames 840
*/

$list = range(1,840);

$bt = 0;
$ct = 0;

$bv = 0;
$cv = 0;

foreach($list as $sn){

   if($bt == 7){
   	$bv += 1;
   	$bt = 0;
   }

   if($ct == 14){
   	$cv += 1;
   	$ct = 0;
   }

   $bt++;
   $ct++;

   echo str_pad($sn, 4, '0', STR_PAD_LEFT)," $bv $cv","\n";
}

?>

This was further run from the command line and the output captured in a text file. Further a while loop creates the frames using image magik convert utility.

php -q bnc.php > list.txt

mkdir fg

cat list.txt | while read fi bv cv; do convert scene.jpg -brightness-contrast -${bv}x${cv} fg/${fi}.jpg ; done

cd fg
ffmpeg -i %04d.jpg -i /home/jijutm/Downloads/bgm-sunset.mp3 -r 30 ../sunset-reel.mp4

The bgm-sunset.mp3 was created using AI music generator and edited in audacity for special effects like fade in fade out etc.

Why this workflow is effective:

Automation: The PHP script and ImageMagick loop automate the tedious process of creating individual frames, saving a lot of time and effort.
Cost-effective: Using open-source tools like GIMP and FFmpeg keeps the cost down.
Flexibility: This approach gives a high degree of control over every aspect of the video, from the scenery to the music and the visual effects.
Efficient: By combining the strengths of different AI tools and traditional image/video processing software, this streamlined workflow is defined that gets the job done quickly and effectively.

The final reel on facebook page , see that also.

Exploring Animation Creation with GIMP, Bash, and FFmpeg: A Journey into Headphone Speaker Testing

For a long time, I had a desire to create a video that helps people confirm that their headphones are worn correctly, especially when there are no left or right indicators. While similar solutions exist out there, I decided to take this on as an exploration of my own, using tools I’m already familiar with: GIMP, bash, and FFmpeg.

This project resulted in a short animation that visually shows which speaker—left, right, or both—is active, syncing perfectly with the narration.

Project Overview:
The goal of the video was simple: create an easy way for users to verify if their headphones are worn correctly. The animation features:

  • “Hear on both speakers”: Animation shows pulsations on both sides.
  • “Hear on left speaker only”: Pulsations only on the left.
  • “Hear on right speaker only”: Pulsations only on the right.
  • Silence: No pulsations at all. Tools Used:
  • Amazon Polly for generating text-to-speech narration.
  • Audacity for audio channel switching.
  • GIMP for creating visual frames of the animation.
  • Bash scripting to automate the creation of animation sequences.
  • FFmpeg to compile the frames into the final video.
  • LibreOffice Calc to calculate frame sequences for precise animation timing. Step-by-Step Workflow:
  1. Creating the Audio Narration:
    Using Amazon Polly, I generated a text-to-speech audio file with the necessary instructions. Polly’s lifelike voice makes it easy to understand. I then used Audacity to modify the audio channels, ensuring that the left, right, and both channels played at the appropriate times.
  2. Synchronizing Audio and Visuals:
    I needed the animation to sync perfectly with the audio. To achieve this, I first identified the start and end of each segment in the audio file and created a spreadsheet in LibreOffice Calc. This helped me calculate the number of frames per segment, ensuring precise timing for the animation.
  3. Creating Animation Frames in GIMP:
    The visual animation was created using a simple diaphragm depression effect. I made three frames in GIMP:
  • One for both speakers pulsating,
  • One for the left speaker only,
  • One for the right speaker only.
  1. Automation with Bash:
    Once the frames were ready, I created a guideline text using Gedit that outlined the sequence. I then used a bash while-read loop combined with a seq loop to generate 185 image files. These files followed a naming convention of anim_%03d.png, ensuring they were easy to compile later.
  2. Compiling with FFmpeg:
    After all frames were created, I used FFmpeg to compile the images into the final video. The result was a fluid, synchronized animation that matched the audio perfectly. The Finished Product:
    Here’s the final video that demonstrates the headphone speaker test:

https://youtu.be/_fskGicSSUQ

Why I Chose These Tools:
Being familiar with xUbuntu, I naturally gravitated toward tools that work seamlessly in this environment. Amazon Polly provided high-quality text-to-speech output, while Audacity handled the channel switching with ease. GIMP was my go-to for frame creation, and the combination of bash and FFmpeg made the entire animation process efficient and automated.

This project not only satisfied a long-held desire but also served as an exciting challenge to combine these powerful tools into one cohesive workflow. It was a satisfying dive into animation and audio synchronization, and I hope it can help others as well!

Conclusion:
If you’re into creating animated videos or simply exploring new ways to automate your creative projects, I highly recommend diving into tools like GIMP, bash, and FFmpeg. Whether you’re on xUbuntu like me or another system, the potential for customization is vast. Let me know if you found this helpful or if you have any questions!

Playing with Gimp on Ubuntu and AI

Recently I decided to brush up my graphics exposure. Since long back I have had the opportunity to explore using Adobe Photoshop on Windows, and Gimp or Ink-Scape on Linux, Canva on Android and most recently with AI using leonardo AI and Microsoft Copilot. Will boast about all of these with examples and prompts used.

The recent exploration using Gimp follows.

The original images are as follows though the one used for top layer was taken on Samsung M14 and file type was hief and the size was too large for the upload limits set by me on this blog and is down sized to acceptable file size loosing some quality.

The road picture shown above is snatched from google and tweaked a bit. For mixing up the first picture of my and my car had to be converted to a rotoscopic one with unwanted area having single color or transparency. This was done in gimp by pasting on a second layer and adding alpha channel to the layer. Then using fuzz select “U” and “Selection Editor” menu and “shift” + “click” “Select -> Grow / Shrink / Remove Holes” menu items and “Tools -> Paint tools -> Eraser ” or “Shift + E” visually and manually erased all unwanted elements leaving out only me and my car in the layer. This layer ws further resized after reducing the opacity to see how it matched the road picture, once the proportion was visibly satisfied the opacity was taken back to 100% and to finalize using “Tools -> Paint Tools -> Clone” and own visual decision some shadow from my Shirt was also stamped out to match the sun light angle in the road picture. Hope everything is visually okay.

Further playing with AI

A 90-year-old biker wearing full riding gear, including a leather jacket, helmet with a visor, gloves, and riding boots, sitting confidently on a large cruiser motorcycle. His weathered face shows deep lines of age, but his posture remains strong and determined. The motorcycle is a classic, chrome-laden cruiser, polished and shining under the sunlight. The backdrop features a vast, sprawling farm with rolling green fields, a rustic barn, and distant hills under a clear blue sky. The atmosphere is peaceful, yet the image exudes a sense of timeless adventure and freedom.

From the view of this image, I went to google photos on my device and searched for my images to choose the one included below

Original image taken on Samsung M14 and had 7.3 MB and 4896×5789 resolution so rescaled it to 1096×1296 and 1.1 mb to fit into this blog.

from the image only the face was selected with gimp Tools -> Selection Tools -> Rectangle Select “R”, I always use the hot key “r” and was copied into the other AI rendered image as a new layer. This was scaled to fit the size after erasing unwanted edges and the final image is as follows.

Well there are more to it and that will be another story.
